Small Size High Power High Rpm 12v 24v Gear Motor for Vacuum Cleaner/cordless Power Tools/sewing Machine
Product Description
Small Size High Power High RPM 12V 24V Gear Motor for Vacuum Cleaner / Cordless Power Tools / Sewing Machine
⚡ Promotion
⚙️ Product Description
| PMDC MOTOR Technical Data | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Model | Rated Voltage(V) | No-Load | Rated | Stall | |||||||
| Operating Range | Nominal | Speed | Current | Speed | Current | Torque | Power | Current | Torque | ||
| RPM | A | RPM | A | mN.m / gf.cm | W | A | mN.m / gf.cm | ||||
| RS-550H | 23128R | 6.0~24.0 | 24VDC | 4500 | 0.1 | 3932 | 0.39 | 25.7/262 | 10.6 | 4.8 | 204/2080 |
| 6034 | 6.0~12.0 | 12VDC | 16000 | 1.12 | 13613 | 4.96 | 25.6/261.3 | 40.36 | 48.89 | 281.4/2870 | |
| RS-555H | 3540 | 6.0~12.0 | 12VDC | 7800 | 0.3 | 6708 | 1.84 | 21.9/223.4 | 15.35 | 11.31 | 156/1591 |
| 23100 | 6.0~24.0 | 24VDC | 7000 | 0.14 | 6004 | 0.77 | 19.2/195.8 | 12.09 | 4.2 | 124.5/1270 | |
💡 Application
⭐ Customer Evaluation
📜 Certifications
👍 Recommended Products
❓ FAQ
1Are you a trading company or manufacturer?
We are a factory. We specialize in micro DC motors and DC gear motors with more than 14 years of experience.
2What is the payment term for new customers?
We can draw up an Online Assurance Order for our new customers, which can be paid online with Mastercard, Visa, etc. Customers can also pay via PayPal, T/T, and other methods.
3I cannot find a suitable motor on your website, can you customize the motor for me?
Yes, we can customize a suitable motor according to our customers' technical specifications and requirements.
4Do you have certificates for the motors?
Yes, we have CE, FCC, ISO, and other relevant certificates. If you have other specific certificate requirements, we can apply for them for you.
5How is your Quality Control?
We have professional quality inspectors on every production line process. Once the motor is fully assembled, we test it using a variety of quality testing equipment, including Hardness Testers, 2.5D Image Testers, Salt Spray Chambers, Life Testers, Temperature Test Machines, and Noise Testers.
6What are the main applications of these 12V/24V gear motors?
These micro DC gear motors are highly versatile and ideal for vacuum cleaners, cordless power tools, sewing machines, smart home devices, and other automated mechanical devices requiring high RPM and power.
