SRC-370SH-4730 Factory Hot Selling 4.5V 17500rmp 3.63A Output 11.51W
Product Description
SRC-370SH-4730 Factory Hot selling 4.5V 17500rmp 3.63A output 11.51W
Product Description
| PMDC MOTOR Technical Data | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Model | Rated Voltage (V) | No-Load | Rated | Stall | |||||||
| Operating Range | Nominal | Speed | Current | Speed | Current | Torque | Power | Current | Torque | ||
| RPM | mA | RPM | mA | mN.m / gf.cm | W | mA | mN.m / gf.cm | ||||
| RF-370CA | 061700 | 6.0~24.0 | 24 VDC | 1320 | 3 | 1000 | 8 | 0.98/10 | 0.1 | 260 | 4.02/41 |
| RC-370CH | 20123 | 3.0~6.0 | 6 VDC | 8000 | 70 | 6878 | 420 | 2.4/24.5 | 1.71 | 2550 | 17/173 |
| RC-370SH | 4730 | 3.0~5.0 | 4.5 VDC | 17500 | 550 | 15199 | 3630 | 7.2/73.4 | 11.51 | 24000 | 55/561 |
| 18139 | 6.0~12.0 | 12 VDC | 10000 | 130 | 8439 | 700 | 5.8/59.2 | 5.17 | 3800 | 37.5/382.5 | |
Refer to the italicized parameters in the technical table for detailed configurations.
Application
Frequently Asked Questions
What is the rated voltage and speed of the SRC-370SH-4730 motor?
The SRC-370SH-4730 motor has a nominal rated voltage of 4.5V DC and features a high no-load speed of 17,500 RPM. Its operating voltage range spans from 3.0V to 5.0V.
What is the maximum output power of the RC-370SH-4730 model?
According to the technical specifications, the motor provides a rated output power of 11.51W, achieving high efficiency for compact PMDC micro motor designs.
In what typical environments are these micro PMDC motors used?
These motors are widely integrated into children's toys, smart appliances, automatic security systems, low-noise planetary and worm geared assemblies, and mini battery-powered electronic devices.
What are the key technical specifications under stall conditions for the 4.5V model?
Under stall conditions, the RC-370SH-4730 motor operates at a current limit of 24,000 mA (24A) and yields a stall torque of 55 mN.m (561 gf.cm).
Does this product line offer configurations with different operating voltages?
Yes, the series includes multiple configurations such as the RF-370CA (operating at 24 VDC), the RC-370CH (operating at 6 VDC), and other RC-370SH models designed for 12 VDC.
Can these technical specifications be customized?
Yes, these technical parameters represent typical values. The winding design, operating voltage range, shaft specifications, and speed/torque profiles can be customized to suit specific application demands.
